Extraction Thimbles

Microlab offers a wide selection of high-quality extraction thimbles available in a variety of dimensions to fit most soxhlet extraction units.Our extraction thimbles are manufactured in high purity cellulose fibers or high purity glass binder-free microfiber.They also feature a consistent wall thickness customized manufacturing is available for tubes, sleeves and additional sizes.

1.Soxhlet extraction
2.Air and waste gas analysis
3.Collection of solid particles such as dust
4.Smokestack gas monitoring
5.Analysis of pesticide residues
6.Oil/fat content of solid foods
7.Oil & grease analysis of solid wastes
8.Elution for biochemical analysis

Send Inquiry
Description

TECHNICAL SPECIFICATION



Type of Extraction Thimbles

 Max.temperature(℃)

 Binder

Wall  thickness(mm)

 Rate Pore size

Cellulose   120   None    1.3   8um
Glass Microfiber     500   None     2.0  8um

ORDER INFORMATION



P/N

  Material

 Size(mm) OD*Height

 Wall Thickness(mm)

 Package(pcs)

ETC1733  Cellulose    17*33  1.0-1.5  25
ETC1990 Cellulose   19*90 1.5-2.0 25
ETC2260 Cellulose   22*60 1.5-2.0 25
ETC2660  Cellulose   26*60 1.5-2.0 25
ETC2780 Cellulose   27*80 1.5-2.0 25
ETC3060 Cellulose   30*60 1.5-2.0 25
ETC30100 Cellulose   30*100 1.5-2.0 25
ETC3380 Cellulose   33*80 1.5-2.0 25
ETC3480 Cellulose   34*80 1.5-2.0 25
ETC3680 Cellulose   36*80 2.0-2.5 25
ETC36100 Cellulose   36*100 2.0-2.5 25
ETC37130 Cellulose   37*130 2.0-2.5 25
ETC41150 Cellulose   41*150 2.5-3.0 25
ETC58170 Cellulose   58*170 2.5-3.0 25
ETC70240 Cellulose   70*240 2.5-3.0 25
ETG32120 GlassMicrofiber  32*120 2.5-3.0 25
ETG2590 GlassMicrofiber  25*90 2.5-3.0 25
ETG2870 GlassMicrofiber  28*70   2.5-3.0 25
